Exedra Gravity OUT Push-To-Open Pocket Door System
Pocket & Concertina Door SystemsKey specifications
- suitable for worktop height doors from 1100mm
- Gravity OUT with push-to-open extraction from the pocket
- no cables, tie rods or springs
- OUT version ideal for handleless kitchens
- for door heights from 1100mm to 3000mm
- for door widths from 300mm to 900mm
- for door thickness from 16mm to 30mm
- maximum door weight 40kg **
- available with nickel or titanium hinges
- push-to-open or soft-close hinge kit available
- easy adjustment
- fits to cabinet side
- door vertical adjustment +4/-1mm
- door horizontal adjustment ±2mm
- door front adjustment ±4mm
- customised to your bespoke requirements
- made to order
Product codes & finishes
Select and quote the product code when ordering.
| item | height | handing | hinge colour | code |
|---|---|---|---|---|
| OUT short soft-close | 1100-1599mm | LH | nickel | VE55GRAS1600SN |
| OUT short soft-close | 1100-1599mm | RH | nickel | VE55GRAD1600SN |
| OUT short push-to-open | 1100-1599mm | LH | nickel | VE55GRAS1600PN |
| OUT short push-to-open | 1100-1599mm | RH | nickel | VE55GRAD1600PN |
| OUT short soft-close | 1100-1599mm | LH | titanium | VE55GRAS1600ST |
| OUT short soft-close | 1100-1599mm | RH | titanium | VE55GRAD1600ST |
| OUT short push-to-open | 1100-1599mm | LH | titanium | VE55GRAS1600PT |
| OUT short push-to-open | 1100-1599mm | RH | titanium | VE55GRAD1600PT |
| OUT tall soft-close | 1600-3000mm | LH | nickel | VE55GRAS3000SN |
| OUT tall soft-close | 1600-3000mm | RH | nickel | VE55GRAD3000SN |
| OUT tall push-to-open | 1600-3000mm | LH | nickel | VE55GRAS3000PN |
| OUT tall push-to-open | 1600-3000mm | RH | nickel | VE55GRAD3000PN |
| OUT tall soft-close | 1600-3000mm | LH | titanium | VE55GRAS3000ST |
| OUT tall soft-close | 1600-3000mm | RH | titanium | VE55GRAD3000ST |
| OUT tall push-to-open | 1600-3000mm | LH | titanium | VE55GRAS3000PT |
| OUT tall push-to-open | 1600-3000mm | RH | titanium | VE55GRAD3000PT |
| roller guide for framed wooden doors /pair | - | - | - | YE55KIT0040 |
| top mount connector | - | - | - | YE55KIT0002 |
| side mount connector | - | - | - | YE55KIT0006 |
| double pocket connector | - | - | - | YE55KIT0004 |
| front cover strip, grey | - | - | - | YE55KIT0201 |
| front cover strip, black | - | - | - | YE55KIT0202 |
| front cover strip, white | - | - | - | YE55KIT0203 |
