Salice Mover

Runners, Flap Stays & Hinges

Key specifications

vertical sliding system for wall cabinet doors
particularly suitable for restricted spaces as an alternative to conventionally opening doors
popular for living room or media wall applications
door can be parked in any position between open and closed
maximum door weight from 6-23kg
available for door widths of 900, 1200, 1800 and 2400mm
available for door heights of 480 and 600mm
for 18-20mm cabinet panel thickness
+/- 3mm height adjustment
+/- 2mm vertical adjustment
for door widths of 1800 and 2400mm the system will require a third runner and machining of the centre panel

Enquire about this product

Product codes & finishes

Select and quote the product code when ordering.

door height	door width	door weight	thickness of the cabinet side	code
480 mm	900mm	6-8kg	18mm	VE2809004818
480 mm	1200mm	7-9kg	18mm	VE2812004818
480 mm	1800mm	10-12kg	18mm	VE2818004818
480 mm	2400mm	15-17kg	18mm	VE2824004818
480 mm	900mm	6-8kg	19/20mm	VE2809004820
480 mm	1200mm	7-9kg	19/20mm	VE2812004820
480 mm	1800mm	10-12kg	19/20mm	VE2818004820
480 mm	2400mm	15-17kg	19/20mm	VE2824004820
600mm	900mm	6-8kg	18mm	VE2809006018
600mm	1200mm	10-12kg	18mm	VE2812006018
600mm	1800mm	15-17kg	18mm	VE2818006018
600mm	2400mm	21-23kg	18mm	VE2824006018
600mm	900mm	6-8kg	19/20mm	VE2809006020
600mm	1200mm	10-12kg	19/20mm	VE2812006020
600mm	1800mm	15-17kg	19/20mm	VE2818006020
600mm	2400mm	21-23kg	19/20mm	VE2824006020
